SPECS :

Frequency Response:

20 - 20,000 Hz

Channel Separation

18dB (1kHz)

Vertical Tracking Angle :

20°

Stylus Construction

Bonded Round Shank

Recommended Load Impedance

47,000 Ω

Coil Inductance :

400 mH (1 kHz)

Output Voltage

3.5 mV (@ 1 kHz, 5 cm/sec)

Output Channel Balance :

2.5 dB (1 kHz)

Stylus Shape :

Conical

Cantilever :

Carbon Fibre Reinforced ABS

Mounting :

P-Mount

Diamensions :

17.2 x 18.9 x 28.3 ( H x W x D mm)

Recommended Load Capacitance :

100-200 pF

Replacement Stylus :

ATN81CP

Stylus Size :

0.6 mil

Type :

Dual Magnet

Weight :

6.0g
